Maule Aircraft Australia

Comet

MAULE COMET SPECIFICATIONS - MXT-7-160

Engine, Lycoming: O-320-B2D
Propeller, Sensenich: 2 Blade, 74inch
Wing Span: 10.028m
Wing Area: 15.38sq m
Length: 7.163m
Height: 2.53m
Cabin Width: 1.07m
Configuration: 4 place
Gross Weight: 998kg
Weight: 649kg
Useful Load: 349kg
Fuel Capacity: 277L
Stall Speed (full flaps, 1 POB, 1/2 fuel): 39kts
Take Off (1 POB, 1/2 fuel): 183m
Take Off at Gross over 50ft Obstacle: 360m
Rate of Climb (1 POB, 1/2 fuel): 825fpm
Land at Gross over 50ft Obstacle: 152m
Best Climb Speed: 78kts
Service Ceiling: 13 000ft
Fuel Consumption (65% power): 30lph
Range, Max (30min reserve): 880nm
Cruise (75% power at opt altitude): 113kts
Flap Settings: -7, 0, 24, 40


MAULE COMET SPECIFICATIONS - MXT-7-180A

Engine, Lycoming: O-360-C4F
Propeller, Sensenich: 2 Blade, 76inch
Wing Span: 9.754m
Wing Area: 15.38sq m
Length: 7.163m
Height: 2.53m
Cabin Width: 1.07m
Configuration: 4 place
Gross Weight: 1089kg
Weight: 658kg
Useful Load: 431kg
Fuel capacity: 277L
Stall Speed (full flaps, 1 POB, 1/2 fuel): 39kts
Take Off (1 POB, 1/2 fuel): 920fpm
Take Off at Gross over 50ft Obstacle: 350m
Rate of Climb: 920fpm
Land at Gross over 50ft Obstacle: 152m
Best Climb Speed: 78kts
Service Ceiling: 15 000ft
Fuel Comsumption (65% power): 34lph
Range, Max (30min reserve): 780nm
Cruise (75% power at opt altitude): 117kts
Flap Settings: -7, 0, 24, 40
