Maule Aircraft Australia

Trigears

MAULE MT7-235B SUPER ROCKET TRIGEAR

Engine: Lycoming IO-540, 2000 hours T.B.O.
Propeller, Hartzel constant speed: 81"
Wing Span: 9.982m
Wing Area: 15.37 sq m
Length: 7.163m
Height: 2.54m
Cabin Width: 1.07m
Configuration: 5 place
Gross Weight: 1134kg
Empty Weight: 705kg
Useful Load: 431kg
Cargo (seats removed): 350kg
Fuel Capacity: 276L
Stall Speed (1 POB, 1/2 fuel, full flaps): 35kts
Take Off (1 POB, 1/2 fuel): 61m
Take Off at Gross over 50ft Obstacle: 183m
Rate of Climb (1 POB, 1/2 fuel): 1700fpm
Land at Gross over 50ft Obstacle: 152m
Best Climb Speed: 78kts
Service Ceiling: 20 000ft
Fuel Consumption (65% power): 45lph
Range, max (45min reserve): 800nm
Cruise (75% power, opt. alt.): 138kts
Flap Settings: -7, 0, 24, 40, 48°


MAULE MXT-7-180 STAR ROCKET TRI-GEAR

Engine: Lycoming O-360 2000 hours T.B.O.
Propeller, Hartzel constant speed: 1.930m
Wing Span: 9.982m
Wing Area: 15.38sq m
Length: 7.163m
Height: 2.54m
Cabin Width: 1.07m
Configuration: 4/5 place
Gross Weight: 1134kg
Empty Weight: 640kg
Useful Load: 495kg
Baggage: 114kg
Cargo (seats removed): 350kg
Fuel Capacity: 320L
Stall Speed (1 POB, 1/2 fuel, full flaps): 35kts
Take Off (1 POB, 1/2 fuel): 61m
Take Off at Gross over 50ft Obstacle: 183m
Rate of Climb (1 POB, 1/2 fuel): 1200fpm
Land at Gross over 50ft Obstacle: 152m
Best Climb Speed: 78kts
Service Ceiling: 15 000ft
Fuel Consumption: (65% power)
Range, max (45min reserve): 800nm
Cruise (75% power opt. alt.): 120kts
Flap Settings: -7, 0, 24, 40, 48°
